The patio heater has three heat settings. Press once for the maximum output (2500 W), once more for medium output (1650 W) and a third time for lowest output (825 W).

The innovative ULG+ heating lamp emits a much more pleasant light than we were used to in the past. The patio heater reduces your carbon footprint compared to gas heaters as it is electrically powered, with the added bonus that it never runs out of fuel. For using in all types of weather throughout the year.

Remote control
When you connect your patio heater to the power supply and switch on the main switch on the back of the appliance, a blue light will illuminate to indicate that the heater is switched on. The patio heater is operated by means of the accompanying battery-powered remote control (two AAA batteries not included). Insert the batteries into the remote control by removing the cover on the back.

When you switch on the heat using the remote control,

the blue light will switch off after 5 seconds. As soon

as you choose to switch off the heat using the remote

control, a stand-by lamp switches on to indicate that

the patio heater is connected to the power supply.

How to install your patio heater
Install your patio heater outdoors on a wall at a height of min. 1.85 metres. If you want to fit the patio heater under an awning etc. which is made of flammable material, you must ensure a min. distance of 35 cm. The patio heater must be installed horizontally.

Technical data
Voltage: 230 V AC
Frequency: 50-60 Hz
Wattage: 2,500 W
Min. fuse: 13 A
Certifications: GS, CE, TüV
Water resistance: IP65
Heat dispersion: 4.5 x 2.8 x 1.8 m
The patio heater can be fitted in three different positions with an angling of 0-48° from innermost to outermost fitting point.
Installation height: Min. 1.85 m.
